Metal Seat Lug Type Butterfly Valve
Metalic seal butterfly valve wafer type/lug type
Metal seal butterfly valve are eccentric butterfly valve.There are tri-eccentric butterfly valve and double eccentric butterfly valve. The tri-eccentric butterfly valve adopts three dimesioal eccentric multi layer metalic seal structure, it is hard seal. Double eccentric butterfly valve are designed to reduce the friction between seat and seal.Both of them has good performance.
Work pressure (MPA) 1.0~4.0
Applicable temperature (centigrade) less than 300
Suitable for medium water, oil, steam, etc.
Material body:cast steel, stainless steel
Valve stem: 40Cr austenitic stainless steel
Sealing Material: Stainless Steel/Stainless Steel
End: Lug, wafer and double flange
Operation: Manual, Worm and pneumatic actuator
Features:
Good performance between low temperature and high temperature
Wear-resistance, Long service life
Reliable sealing, Unique structure and easy maintenance
Blow-out proof stem
Double eccentric butterfly valve are designed to reduce the friction between the seat and the seal about 15 stroke, and add a special eccentricity angle beta, which not only overcomes all contact friction between the seal and the valve seat in the valve opening and closing.
The service life is increasing, and the sealing pressure can be regulating arbitrarily by changing the applied torque, so that the sealing is more reliable and there is no turning over phenomenon.
