Casting Floating Ball Valve

Casting Floating Ball Valve

1. Designed in accordance with ISO17292,API 608,BS 5351,GB/T 12237;
2. Simple structure with good tightness and small torque;
3. Have reduce bore type and full bore type with the minimum flow resistance (zero actually);
4. Low emission packing;

Send InquiryChat Now


Floating type Ball Valve, Flanged Ball Valve, Cast steel 2piece floating ball Valve, 2piece stainless steel floating ball valve

Floating Ball Valves (Flanged general and butt-welding connection is optional) are suitable for using on various kinds of pipeline from pressure Class 150 to Class 1500, PN16 to PN100 to cut off or connect the flowing of medium. By using different material, the valves could be suitable for medium such as water, steam, oil, nitric acid, acetic acid, oxidizing substance, carbamide and etc. Manual/worm gear/pneumatic or electric actuators could be chosen by needs.


Feature:

1. Designed in accordance with ISO17292,API 608,BS 5351,GB/T 12237;

2. Simple structure with good tightness and small torque;

3. Have reduce bore type and full bore type with the minimum flow resistance (zero actually);

4. Low emission packing;

5. Fire safe, anti-static and anti-blowout stem design;

6. Optional locking device

7. Optional ISO 5211 top flange


Technical

Product Name:

cast steel 2 piece floating ball valve

Size:

1/2"inch to 8inch(DN15 to DN200)

Pressure rating

150LB to 1500LB (PN10 to PN160)

Material:

Carbon steel

End connection:

SW

Operation type

Handwheel, BARE STEM, ISO MOUNTED FLANGE, Worm, pneumatic, electric actuators

Design Standards:

API6D

Face to Face:

ASME B16.10

Test standard:

API598

Fire safety:

API607



Hot Tags: casting floating ball valve, China, manufacturers, factory, buy, price, in stock
